Special mixer for PVC

High performance requirements, new properties of raw materials, sequence of technological processes or increasing quality requirements - there are many reasons for adjusting the parameters of the production line. Often, quality preparation of the first step in the technological chain of the material is not considered properly. However, a well-optimized mixture is the basis of a highly reproducible result. The function of these mixers is to ensure uniform and equal distribution of stabilizers, oil-based materials and modifiers. This mixer turns the mixture into a dust-free, dry state. The heating mixer is designed to heat and mix the material and all parts to a temperature of 110 C to 130 C for 5-8 minutes. This process binds all compounds to the material particles. However, at this temperature, bonding waxes are still somewhat viscous and the composite tends to not compress under pressure. Therefore, the mixture is transferred from the heating mixer to the cooling mixer, where it is cooled to about 40 C. After that, the mixed material is cooled in a vertical cooling mixer. In the next step, the mixed material can be used for ensiling and further processing including extrusion.

01

General

16 parameters

Produced

China

Voltage

380v 50hz

Motor power

11, 55 kw/h

Mixing time

8-12 minutes

Mixing steps

2 stage

hot or cold mixing function

there is

Control Panel

PLC control panel

Heat up

12kw/h

Hot mixer volume

300L

Mixer rotation speed

475-950 r/min

Cold mixer volume

600L

Product release method

Pneumatically

Volume of product at one time

Around 100kg

Production volume

450-500kg/h

Size

2500*2100*3800 mm

Weight

3000 kg
