1 / 10Production line of disposable tubes for drinks AF-L019
We all know that the production of high-demand, disposable products that are used all the time in our daily lives can…
- Model
- AF-ML12
- The tube is diametric
- F 3.0-f12mm
- Voltage
- 380V50Hz
- Weight
- 2100 kg
- Tube thickness
- 0.10-0.35mm
- Size
- 8000x1200x1600mm
Overview
About the equipment
We all know that the production of high-demand, disposable products that are used all the time in our daily lives can bring good profits. Disposable tubes for drinks, which the "AFEX-GROUP" team brings to your attention, are also among the products in high demand. Such tubes are widely used in cafes, bars, restaurants, especially fast-food chains, and at home. Such tubes are a good helper especially for our mothers. Because for children, eating milk products and juices in such tubes is one of their favorite pastimes. Also, in persuading our children who refuse to drink milk products, juices and other types of drinks, our mothers will be helped by various colored, comfortable and eye-catching tubes.
This line consists of the following parts
1. EXTRUDER
The extruder is designed for the production of tubes of all types, one and two colors. The dimensions of the tubes can be changed by changing the dies in the extruder. Also, the extruder has a device for cooling and cutting to the required size using a water tank.
General
- Produced
- China
- Year of manufacture
- 2019
- Model
- AF-ML12
- Raw material type
- PP
- The tube is diametric
- F 3.0-f12mm
- Tube thickness
- 0.10-0.35mm
- Productivity
- 400-1800 units/minute
- Voltage
- 380V50Hz
- Electricity consumption
- 16 sq/h
- Size
- 8000x1200x1600mm
- Weight
- 2100 kg
2. TUBE BENDING EQUIPMENT
The straight tubes coming out of the extruder are bent using the bending equipment. The purpose of bending the tubes is that it is more convenient to drink in such tubes. There is an automatic counting function.
General
- Produced
- China
- Year of manufacture
- 2019
- Model
- AF-ML21-5
- Productivity
- 250-280 units/minute
- Automatic counting function
- There is
- Automatic stop function
- There is
- Voltage
- 380V50hz
- Correct tube length
- 190-260mm
- The length of the bent tube
- 175-245mm
- Electricity consumption
- 1.5 sq/h
- Size
- 1200x1600mm
- Weight
- 1000 kg
3. PACKAGING EQUIPMENT
After bending in the bending machine, the tubes are placed in the packaging equipment with high quality and speed. The equipment is designed for packing tubes in bulk. Paper or bags can be used for packaging. The device also has an automatic counting function. Of course, since tubes are considered a single-use product, packaging is important.
General
- Year of manufacture
- China
- Model
- 2019
- Productivity
- AF-ML31
- Automatic counting function
- 350-450 units/minute
- Voltage
- There is
- packaging
- 380V50Hz
- Package width
- Paper or package
- Electricity consumption
- Paper 25-33, package 25-60
- Size
- 1.5kw/h
- Weight
- 600 kg
Now you can easily take your product to the market. May he give his blessing.
