1 / 1Vertical pouring (dispensing) equipment
Vertical dispenser that fills liquid products into containers in precise doses from 10 to 500 ml.
- Voltage
- 220V 50/60 Hz
- Power
- 10 watts
- Speed of operation
- 4-60 units/min
- Air pressure
- 0.4-0.8 Mpa
- Accuracy level
- ≤±1%
- Filling weight
- 10-100/ 20-200/ 50-500 ml
Overview
About the equipment
Vertical dispenser that fills liquid products into containers in precise doses from 10 to 500 ml. It runs on compressed air and fills 4 to 60 containers per minute.
The dispenser is offered in three volume ranges: 10–100 ml, 20–200 ml and 50–500 ml. Dosing error does not exceed ±1%, so every container receives practically the same volume. It needs compressed air at 0.4–0.8 MPa, while the electrical part runs on 220 V, 50/60 Hz and draws only 10 W.
Working speed ranges from 4 to 60 units per minute and is chosen according to the container size and product. The machine measures 50×40×160 cm, and its vertical layout takes up little workshop space. Made in China, it suits small and medium workshops that fill liquid products into glass and plastic containers.
AFEX supplies the equipment and provides installation, commissioning and warranty service. Tell us your product and container volume, and we will recommend a suitable dosing range.
General
- Produced
- China
- Voltage
- 220V 50/60 Hz
- Power
- 10 watts
- Speed of operation
- 4-60 units/min
- Air pressure
- 0.4-0.8 Mpa
- Accuracy level
- ≤±1%
- Filling weight
- 10-100/ 20-200/ 50-500 ml
- Equipment size
- 50*40*160 cm
Quick price request
Leave your name and phone number — our specialist will take care of the rest.
EquipmentVertical pouring (dispensing) equipmentYour data is never shared with third parties
Specifications
Data provided by the manufacturer; configuration may vary per order.
General
8 parameters- Produced
- China
- Voltage
- 220V 50/60 Hz
- Power
- 10 watts
- Speed of operation
- 4-60 units/min
- Air pressure
- 0.4-0.8 Mpa
- Accuracy level
- ≤±1%
- Filling weight
- 10-100/ 20-200/ 50-500 ml
- Equipment size
- 50*40*160 cm
Video
The equipment in operation.
Delivery and commissioning
From consultation to launch — four steps under contract.
Consultation
We define your needs, configure the line and prepare an offer.
Contract
Timeline, payment terms and warranty are fixed in the contract.
Delivery
The equipment is delivered from the manufacturer to your site.
Installation and training
Our specialists commission the equipment and train your operators.
