Vertical Metal Milling Machine VMC1890

This is a vertical machining center designed for high-precision machining, performing milling, drilling and tapping operations on metal and other materials. The machine comes with a GSK control system; at the customer’s request, Fanuc , Mitsubishi and other CNC systems can also be installed. The spindle speed and the number of tools in the tool magazine can also be changed. The price of the machine depends on the technical specifications and the control system chosen by the customer. To get an exact price calculation, click the "Send request" link.

01

General

18 parameters

X-axis travel

1800 mm

Y-axis travel

900 mm

Z-axis travel

800 mm

Distance from spindle nose to table

160-960 mm

Distance from spindle center to column guideway

960 mm

X/Y/Z rapid traverse speed

12/12/12 m/min

Cutting feed rate

1-10 m/min

Table size

2000×900 mm

Table load capacity

1600 kg

T-slot size

5-22×165 mm

Spindle taper

BT50-190

Spindle speed

8000 rpm

Main motor power

18.5 kW

Positioning accuracy (JIS standard)

±0.005/300 mm

Repeat positioning accuracy (JIS)

±0.003 mm

Tool magazine capacity

24 tools

Maximum tool weight

8 kg

Maximum tool length

300 mm

Advantages

A system built with a simple design for easy maintenance, a color display, program control, tool compensation, and program storage and editing capabilities.

Applications

1. Linear and circular contour cutting:

Straight and circular contours can be cut at any angle with high precision; drilling and tapping can also be performed.

1. No backlash:

Motion is driven by ball screws, which prevents low-speed creeping as the load increases and significantly improves speed and accuracy.

1. High reliability:

The use of electrical technology simplifies the mechanical structure, increases reliability and makes maintenance easier.

1. CNC functions:

The standard configuration provides various CNC functions, such as a color LCD screen, various rotation functions, tool compensation, program storage and editing, and more.
