Vertical Metal Milling Machine VMC1580

This vertical machining center is designed for high-precision machining and performs milling, drilling and tapping operations on metal and other materials. The machine comes with a GSK control system; at the customer's request, Fanuc , Mitsubishi and other CNC systems can also be installed. The spindle speed and the tool magazine capacity can be changed as well. The price of the machine depends on the specifications and the type of control system chosen by the customer. To get an exact price, click the “Send request” link.

01

General

18 parameters

X-axis travel

1500 mm

Y-axis travel

800 mm

Z-axis travel

700 mm

Distance from spindle nose to table

155-855 mm

Distance from spindle center to column guideway

882 mm

X/Y/Z rapid traverse speed

15/15/12 m/min

Cutting feed rate

1-10 m/min

Table size

1600 × 800 mm

Table load capacity

1000 kg

T-slot dimensions

5-22 × 135 mm

Spindle taper

BT50-190

Spindle speed

8000 rpm

Main motor power

15 kW

Positioning accuracy (JIS standard)

±0.005/300 mm

Repeatability (JIS)

±0.003 mm

Tool magazine capacity

24 tools

Max. tool weight

8 kg

Max. tool length

300 mm
