1 / 1Semi-Automatic Gummy Candy Molding and Depositing Machine
The BLB-50 is an automatic depositing machine designed to deposit hard and soft candy masses into molds in precise portions.
- Depositing power
- 0.75 kW
- Production capacity
- 30–60 kg/h
- Hopper heating power
- 3 kW
- Model
- BLB-50
- Voltage
- 220 V
- Hard candy depositing speed
- 25–33 strokes/min
Overview
Key advantages
- Suitable for hard and soft candy production
- Accurate, stable operation via the PLC control system
- Pneumatic depositing technology ensures high accuracy
- Twin-hopper depositing system with 20 nozzles
- Ensures uniform product weight
- Food-contact parts are made of stainless steel
About the equipment
The BLB-50 is an automatic depositing machine designed to deposit hard and soft candy masses into molds in precise portions. It is equipped with pneumatic control, a PLC program control system and a twin-hopper depositing mechanism, ensuring accuracy and stability of the production process. The machine deposits candy mass into molds in set portions, helping keep product quality consistent. Parts in direct contact with food are made of stainless steel and fully meet hygiene requirements.
General
- Model
- BLB-50
- Equipment type
- Automatic candy depositing machine
- Control system
- PLC automatic control
- Depositing power
- 0.75 kW
- Number of hoppers
- Two hoppers with 20 nozzles
- Hard candy weight
- 2–6 g
- Soft candy weight
- 2–6 g
- Hard candy depositing speed
- 25–33 strokes/min
- Soft candy depositing speed
- 25–35 strokes/min
- Production capacity
- 30–60 kg/h
- Working pressure
- 0.3–0.5 MPa
- Air consumption
- 0.5 m³/h
- Hopper heating power
- 3 kW
- Voltage
- 220 V, 50 Hz, 1-phase
- Machine dimensions
- 1900 × 920 × 1650 mm
- Weight
- 450 kg
- Material
- Food-contact parts in stainless steel; carbon steel frame with stainless steel cladding
- Function
- Precise portioned depositing of candy mass into molds
Quick price request
Leave your name and phone number — our specialist will take care of the rest.
EquipmentSemi-Automatic Gummy Candy Molding and Depositing MachineYour data is never shared with third parties
Specifications
Data provided by the manufacturer; configuration may vary per order.
General
18 parameters- Model
- BLB-50
- Equipment type
- Automatic candy depositing machine
- Control system
- PLC automatic control
- Depositing power
- 0.75 kW
- Number of hoppers
- Two hoppers with 20 nozzles
- Hard candy weight
- 2–6 g
- Soft candy weight
- 2–6 g
- Hard candy depositing speed
- 25–33 strokes/min
- Soft candy depositing speed
- 25–35 strokes/min
- Production capacity
- 30–60 kg/h
- Working pressure
- 0.3–0.5 MPa
- Air consumption
- 0.5 m³/h
- Hopper heating power
- 3 kW
- Voltage
- 220 V, 50 Hz, 1-phase
- Machine dimensions
- 1900 × 920 × 1650 mm
- Weight
- 450 kg
- Material
- Food-contact parts in stainless steel; carbon steel frame with stainless steel cladding
- Function
- Precise portioned depositing of candy mass into molds
Delivery and commissioning
From consultation to launch — four steps under contract.
Consultation
We define your needs, configure the line and prepare an offer.
Contract
Timeline, payment terms and warranty are fixed in the contract.
Delivery
The equipment is delivered from the manufacturer to your site.
Installation and training
Our specialists commission the equipment and train your operators.
