1 / 7Complete worm production line
220V · 85 kg · 900x950x1300 mm
Individual offer
- Voltage
- 220V
- Equipment weight
- 85 kg
- Equipment size
- 900x950x1300 mm
- Air pressure
- 0.8 Mpa
- Number of hoppers for mustard
- 2 piece
- Size of the hopper for mustard
- 420x320x80
Price
Overview
About the equipment
General information about the line
- Production Capacity: 200 kg/hour
- Raw Material: Mustard
- Voltage: 380/220 V
- Required Area: 25 m² or larger
- Number of Operators: 3 or more
Equipment in the line
- Mustard Dehydration Equipment
- Mixer for Mixing
- Worm Production Equipment
- Drying Cabinet
- Vacuum Packaging Equipment
Water dewatering equipment
The equipment is made of stainless steel.
An additional compressor was added for automatic operation of the equipment Technical characteristics
01
6 parametersGeneral
- Voltage
- 220V
- Number of hoppers for mustard
- 2 piece
- Size of the hopper for mustard
- 420x320x80
- Equipment size
- 900x950x1300 mm
- Equipment weight
- 85 kg
- Air pressure
- 0.8 Mpa
Mixer for mixing
With the mixer, salt and other additional flavors can be added to the mustard and mixed uniformly
Texnik xususiyatlari
- Made in: China
- Voltage: 220V, 50 Hz
- Power Consumption: 1.5 kW/hour
- Speed: 750 rpm (rotations per minute)
- Dimensions: 870 x 520 x 830 mm
- Weight: 130 kg
- Capacity: 60L
Worm production equipment
- Working Process Sequence:
- Loading Mustard into the Hopper
- Cutting or Dividing into Portions
- Shaping into Round Forms
- Finished Product Output
Technical characteristics
- Made in: China
- Voltage: 220V
- Power Consumption: 2.025 kW
- Production Speed: 100-200 kg/hour
- Worm Size (Diameter): 1-7 cm
- Worm Weight: 5-600 g
- Dimensions: 2300 x 470 x 1150 mm
- Weight of the Equipment: 210 kg
Drying cabinet
- Voltage: 220V
- Power Consumption: 5.4 kW
- Temperature Range: 30-90°C
- Production Capacity: 110-150 kg per batch
- Tray Capacity: 24 trays
- Tray Size: 670 x 670 mm
- Material: Stainless Steel
- Dimensions: 880 x 700 x 1380 mm
- Weight: 94 kg
Vacuum packaging equipment 50 cm
Technical characteristics
Technical Specifications:
- Made in: China
- Model: AF-G-500
- Voltage: 220V, 50/60 Hz
- Motor Power: 1 kW
- Sealing Power: 0.75 kW
- Final Vacuum Pressure: 1 KPA
- Material: Stainless Steel
- Chamber Size (LWH): 525 x 525 x 75 mm
- Sealing Length: 500 mm
- Sealing Width: 10 mm
- Vacuum Pump Speed: 20 m³/hour
- Distance from Sealing Panel to Chamber: 440 mm
- Equipment Size: 72 x 72 x 97 cm
Pricing:
AFEX · CONSULTATION
Operators onlineQuick price request
Leave your name and phone number — our specialist will take care of the rest.
EquipmentComplete worm production lineYour data is never shared with third parties
Specifications
Data provided by the manufacturer; configuration may vary per order.
General
6 parameters- Voltage
- 220V
- Number of hoppers for mustard
- 2 piece
- Size of the hopper for mustard
- 420x320x80
- Equipment size
- 900x950x1300 mm
- Equipment weight
- 85 kg
- Air pressure
- 0.8 Mpa
Video
The equipment in operation.
Delivery and commissioning
From consultation to launch — four steps under contract.
Consultation
We define your needs, configure the line and prepare an offer.
Contract
Timeline, payment terms and warranty are fixed in the contract.
Delivery
The equipment is delivered from the manufacturer to your site.
Installation and training
Our specialists commission the equipment and train your operators.
