1 / 3Laser equipment AF-LA13*9
Laser equipment AF-LA13*9 is a CO2 laser cutting and engraving machine with a 1300×900 mm working area.
- Power consumption
- 1.9 Kw/h
- Laser tube
- 80W/100W/150W
- Model
- AF-La13090
- Voltage
- 220v 50hz
- operating speed (sharpening)
- 0-60000mm/min
- Operating speed (cutting)
- 0-40000mm/min
Overview
About the equipment
Laser equipment AF-LA13*9 is a CO2 laser cutting and engraving machine with a 1300×900 mm working area. It processes non-metal materials such as acrylic, plywood, wood, leather, fabric and paper.
The machine is fitted with an 80, 100 or 150 W RECI laser tube. Engraving speed is up to 60,000 mm/min and cutting speed up to 40,000 mm/min. It is controlled with RDWorks (Ruida) software, and files are transferred via USB or Wi-Fi. The table can be lowered to work with thicker items.
The machine runs on 220 V and consumes 1.9 kW, with stepper motor drives. It weighs 370 kg. The set includes a cooling chiller, an exhaust fan and duct, lenses, software and cables. It is a convenient choice for workshops producing signage, souvenirs, furniture décor and models.
AFEX supplies the equipment and provides installation, commissioning and warranty service. Tell us the material and thickness you work with, and we will recommend a suitable laser power.
General
- Manufacturer
- China, Shenzhen
- Model
- AF-La13090
- Work area
- 1300*900mm
- Power consumption
- 1.9 Kw/h
- Voltage
- 220v 50hz
- operating speed (sharpening)
- 0-60000mm/min
- Operating speed (cutting)
- 0-40000mm/min
- software
- RD works Ruida
- Data transfer
- USB2/USB3/WIFI
- Motor type
- Stepper motor
- Possibility to lower the table
- Available (can be removed)
- Material
- Black metal (painted)
- Size
- 1160*1360*1730mm
- Laser tube
- 80W/100W/150W (RECI brand)
- Weight
- Weight 370 Kg
- Cooling chillers
- CW5200
- Standard additions
- Cooling air motor, cooling chiller CW3000, lens, air suction pipe, USB key, Operating software, USB cable, Power supply cable
Quick price request
Leave your name and phone number — our specialist will take care of the rest.
EquipmentLaser equipment AF-LA13*9Your data is never shared with third parties
Specifications
Data provided by the manufacturer; configuration may vary per order.
General
17 parameters- Manufacturer
- China, Shenzhen
- Model
- AF-La13090
- Work area
- 1300*900mm
- Power consumption
- 1.9 Kw/h
- Voltage
- 220v 50hz
- operating speed (sharpening)
- 0-60000mm/min
- Operating speed (cutting)
- 0-40000mm/min
- software
- RD works Ruida
- Data transfer
- USB2/USB3/WIFI
- Motor type
- Stepper motor
- Possibility to lower the table
- Available (can be removed)
- Material
- Black metal (painted)
- Size
- 1160*1360*1730mm
- Laser tube
- 80W/100W/150W (RECI brand)
- Weight
- Weight 370 Kg
- Cooling chillers
- CW5200
- Standard additions
- Cooling air motor, cooling chiller CW3000, lens, air suction pipe, USB key, Operating software, USB cable, Power supply cable
