1 / 4Laser equipment AF-LA13*25
AF-LA13*25 is a laser cutting and engraving machine with a large 1300×2500 mm working area.
- Laser tube
- 100W/150W/200W
- Power consumption
- 1,9LKw/h
- Voltage
- 220v 50hz
- operating speed (sharpening)
- 0-60000mm/min
- Operating speed (cutting)
- 0-40000mm/min
- Weight
- 550 Kg
Overview
About the equipment
AF-LA13*25 is a laser cutting and engraving machine with a large 1300×2500 mm working area. It takes a 100, 150 or 200 W RECI laser tube.
Cutting speed is up to 40,000 mm/min and engraving speed up to 60,000 mm/min. Stepper motors drive the motion, control is through RDWorks (Ruida) software, and files are loaded via USB2, USB3 or Wi-Fi. The table can be lowered and, if needed, removed.
The large working area lets you cut big sheets and long parts in one set-up, which suits workshops making signage structures, furniture and interior parts. The machine runs on 220 V, 50 Hz and consumes 1.9 kW. The frame is painted ferrous metal; it measures 1160×1660×2930 mm and weighs 550 kg. The set includes a cooling chiller, an air cooling motor, an exhaust duct, lenses, a USB key, software and cables.
AFEX supplies the equipment and provides installation, commissioning and warranty service. Tell us the material and its thickness, and we will recommend a suitable laser tube power.
General
- Manufacturer
- China, Shenzhen
- Work area
- 1300*2500mm
- Power consumption
- 1,9LKw/h
- Voltage
- 220v 50hz
- operating speed (sharpening)
- 0-60000mm/min
- Operating speed (cutting)
- 0-40000mm/min
- software
- RD works Ruida
- Data transfer
- USB2/USB3/WIFI
- Motor type
- Stepper motor
- Possibility to lower the table
- Available (can be removed)
- Material
- Black metal (painted)
- Size
- 1160*1660*2930mm
- Laser tube
- 100W/150W/200W (RECI brand)
- Weight
- 550 Kg
- Cooling chillers
- CW5200
- Standard additions
- Cooling air motor, cooling chiller, lenses, air suction pipe, USB key, Operating software, USB cable, Power supply cable
Quick price request
Leave your name and phone number — our specialist will take care of the rest.
EquipmentLaser equipment AF-LA13*25Your data is never shared with third parties
Specifications
Data provided by the manufacturer; configuration may vary per order.
General
16 parameters- Manufacturer
- China, Shenzhen
- Work area
- 1300*2500mm
- Power consumption
- 1,9LKw/h
- Voltage
- 220v 50hz
- operating speed (sharpening)
- 0-60000mm/min
- Operating speed (cutting)
- 0-40000mm/min
- software
- RD works Ruida
- Data transfer
- USB2/USB3/WIFI
- Motor type
- Stepper motor
- Possibility to lower the table
- Available (can be removed)
- Material
- Black metal (painted)
- Size
- 1160*1660*2930mm
- Laser tube
- 100W/150W/200W (RECI brand)
- Weight
- 550 Kg
- Cooling chillers
- CW5200
- Standard additions
- Cooling air motor, cooling chiller, lenses, air suction pipe, USB key, Operating software, USB cable, Power supply cable
Delivery and commissioning
From consultation to launch — four steps under contract.
Consultation
We define your needs, configure the line and prepare an offer.
Contract
Timeline, payment terms and warranty are fixed in the contract.
Delivery
The equipment is delivered from the manufacturer to your site.
Installation and training
Our specialists commission the equipment and train your operators.
