Hard cover register folder production line for documents

Availability:

Out of stock


Although the times are changing and all documents will be transferred online, the traditional storage and use of documents in paper form will never disappear. Since documents are used a lot in businesses and organizations, it is very important to organize them. Folders for archival files have a great place in organizing documents. Using this folder, you can arrange documents by date, type name, and other criteria.

$53,900

Out of stock

Hardcover register folder types for documents vary in size

Length (mm) Width (mm) Thickness (mm)
214 302 50
280 318 55
285 320 70
290 345 75
290 345 80
290 345 85
290 345 90

With our line, you can produce folders of all sizes listed above

General information

  1. Required area: 15*8 meters 120 square meters
  2. Electric energy capacity: 11 kilowatts/hour
  3. Voltage: 380 V 50 Hz
  4. Number of employees: 5-6 people
  5. Production capacity: finished product 600-700 units/hour

List of required equipment

  1. Cardboard paper cutting equipment
  2. PP coating coating equipment
  3. Folder shaping equipment
  4. Punching equipment
  5. Equipment for installation of small ring and arch mechanism
  6. Big ring mounting hardware
  7. Oval ring installation equipment
  8. Equipment for gluing a metal part to the edge of a folder
  9. Pocket gluing device

Necessary raw materials

  1. Cardboard paper
  2. Metal accessories
  3. Liquid glue
  4. PP coating



Cardboard paper cutting equipment

With the help of cutting equipment, cardboard papers are cut to special sizes. Cardboard paper raw material is sold in the standard size of 920×1250 mm. Folders for files need a maximum of 590×345 mm cardboard paper.

Cutting equipment
Produced China
Tension 380V 50 Hz
Energy consumption 1.1 KW
Size 2150x650x1000 mm
Weight 450 kg
Production speed 180 meters/min
Maximum carton capacity 1750 mm



PP coating coating equipment

Ready-cut PP covers and cardboard papers are placed on this equipment. At the first stage, liquid glue is automatically applied to PP covers using the equipment and transferred to the conveyor. At the next stage, cardboard paper is placed on top of the PP coating and continues to move through the conveyor. In the final stage, the product reaches the end of the equipment. Here, the PP coating and the cardboard paper are passed through the equipment rollers to ensure a strong adhesion, and here the PP coating is folded and glued to the edges of the cardboard paper. This equipment is semi-automatic, and the workers are only responsible for placing the cardboard on the PP coating.

PP coating coating equipment
Produced China
Voltage 380V
Energy consumption 2 kw/h
Maximum capacity 450x900mm
Minimum capacity 90x150mm
Height capacity 1-3 mm
Weight 1900 kg
Size 8000x1140x1380mm
Production speed 10-20 pieces/min

Folder shaping equipment

After the cardboard paper and PP cover are glued together, a folder forming machine is needed to form a complete folder. The product placed on the equipment is pressed with the help of a press. In this process, parallel lines appear on the folder. Grooves are needed for folder folding.

Folder shaping equipment
Produced China
Voltage 380V 50 Hz
Energy consumption 1.1 KW
Size 900x870x1000 mm
Weight 320 kg
Production speed 10-20 pieces/min



Punching equipment

Perforating equipment opens special holes for installation of metal ring and arched mechanism. The advantage of this equipment is that the equipment drills all the necessary holes at the same time, while previous models required a separate equipment for each hole.

Drilling equipment
Produced China
Voltage 380V 50 Hz
Energy consumption 0.55 KW
Size 500x1000x1500 mm
Weight 210 kg
Production speed 10-20 pieces/min



Small ring and arch mechanism installation equipment

With the help of the equipment, it is possible to install an arched mechanism and small rings. The equipment is equipped with a pedal, and when the pedal is pressed, it hardens the arched mechanism.

Equipment for installation of small ring and arch mechanism
Produced China
Voltage 380V 50 Hz
Energy consumption 0.55 KW
Size 900x105x1400 mm
Weight 210 kg

Large loop installation equipment

This equipment fastens metal rings into a large hole made in the folder.

A pedal is installed on the equipment for convenient operation.

Folders are stored densely in cabinets and shelves, and these large rings help to make them easy to access.

Big ring installation equipment
Produced China
Voltage 380V 50 Hz
Energy consumption 0.55 KW
Size 450*650*1580 mm
Weight 120kg
Production speed 10-20 psc min



Oval ring installation equipment

This equipment assumes the function of solidification of oval metal rings. Oval-shaped rings are necessary for the arch mechanism to be located when the folder is closed. In this case, the folder will not become thick and will be comfortable.

Oval ring installation equipment
Produced China
Voltage 380V 50 Hz
Energy consumption 0.55 KW
Size 850*900*1680 mm
Weight 360 kg
Production speed 10-20 piece/ min



Equipment for gluing a metal part to the edge of a folder

Since the folders are kept in the vertical position in the cabinets and shelves, the edge of the folder is quickly corroded and unusable, to eliminate this, metal parts are installed on the edge of the folder. The device for gluing a metal part to the edge of the folder helps for this.

Equipment for gluing a metal part to the edge of a folder
Produced China
Voltage 380V 50 Hz
Energy consumption 0.55 KW
Size 700*900*1400mm
Weight 210 kg
Production speed 5-10 piece/ min



Pocket gluing equipment

A pocket gluing device creates a special pocket for placing labels for naming a folder or writing notes.

Businesses and organizations use file folders a lot. In order to remember what document is stored in the folders, note, date, company names are written on the labels. Labels are put in pockets. For this reason, a special pocket is installed on the side of the folders.

Equipment for gluing a metal part to the edge of a folder
Produced China
Voltage 380V 50 Hz
Energy consumption 1 KW
Size 760*930*1500
Weight 120 kg
