1 / 2CEMS Stations: Continuous Multi-Gas Monitoring System for Industrial Plants
Benefits of implementation: Risk reduction Compliance with environmental requirements reduces scrutiny from inspectors.
Individual offer
- Power supply
- 220 V
- Output signals
- 4–20 mA, RS485, TCP/IP
- Model
- SG1220
- Methane
- CH₄ · 0–300 mg/m³
- Nitrogen oxides
- NO, NO₂ · 0–300 mg/m³
- Carbon oxides
- CO, CO₂ · 0–300 mg/m³
Price
Overview
About the equipment
Benefits of implementation: Risk reduction Compliance with environmental requirements reduces scrutiny from inspectors. Environmental efficiency Makes it possible to assess how advisable it is to introduce modern technologies aimed at improving environmental safety in production. Improves the environmental situation at the plant site and in nearby settlements. Easier permitting Significantly simplifies the process of obtaining integrated environmental permits. Better quality of life for employees An environmentally safe work process creates a comfortable and healthy working environment for employees.
CEMS Stations: Continuous Multi-Gas Monitoring System for Industrial Plants
Specifications
01
5 parametersMeasured Components and Measurement Ranges
- Component
- Symbol · Measurement range, mg/m³
- Methane
- CH₄ · 0–300 mg/m³
- Nitrogen oxides
- NO, NO₂ · 0–300 mg/m³
- Carbon oxides
- CO, CO₂ · 0–300 mg/m³
- Sulfur dioxide
- SO₂ · 0–100 mg/m³
02
5 parametersGaseous Pollutant Monitoring Subsystem
- Item
- Model and description
- Gas analyzer
- SG1220
- Sampling probe
- PSG355
- Sample conditioning system
- CEMS1220
- Electrically heated sampling line
- Dual-core
03
4 parametersData Acquisition and Processing Subsystem
- Item
- Description
- Data acquisition and processing system
- Hardware and software complex including a computer
- Switching cabinet
- JCB265
- CEMS monitoring software V2.0
- CEMS Monitor
VOC (Volatile Organic Compounds) Online Monitoring System
04
5 parametersVOC Monitoring Subsystem
- Item
- Model · Note
- Online VOC analyzer
- VM1700-N · Methane (CH₄)
- Gas sample conditioning system
- — · Includes filtration, condensation and heating
- Electrically heated sampling line
- Stainless steel · Length 500 mm, +5…+300 °C
- Sampling probe
- PSG355 · Stack diameter 1500 mm
05
3 parametersData Acquisition Subsystem
- Item
- Description
- Data acquisition system (with computer)
- —
- VOC monitoring software
- CEMSmonitor V1.0
06
4 parametersPneumatic System
- Item
- Model · Note
- Hydrogen generator
- SPH-300AT · 0.7–3.0 bar
- Zero air generator
- ZA1700 · For calibration and purging
- Compressed air purification system
- — · 99.9% purification efficiency
07
2 parametersAuxiliary Materials
- Item
- Description
- Commissioning accessories kit
- —
08
14 parametersUnit 8
- Measured components
- CH₄, CO, CO₂, NO, NO₂, SO₂
- Measurement range
- 0–300 mg/m³; SO₂ – 0–100 mg/m³
- Measurement method
- UV-DOAS differential spectroscopy
- Sample temperature
- +5…+300 °C
- Ambient temperature
- –20…+70 °C
- Sample pressure
- 0.7–3.0 bar
- Ingress protection
- IP50 / IP54
- Output signals
- 4–20 mA, RS485, TCP/IP
- Power supply
- 220 V, 50 Hz
- Stack diameter
- 1500 mm
- Emission source height
- 35 m
- Probe material
- Stainless steel
- Access control
- Protection against unauthorized opening
- Alarm signaling
- Dry contacts, configurable
09
5 parametersAdditional Equipment
- Item
- Description
- UPS 3000 VA
- 60–120 minutes of backup autonomy
- Cabinet air conditioning system
- Protection at temperatures of +45 °C and above
- IP66 cabinet
- Outdoor type, with thermal insulation
- GSM/4G module
- For data transmission to the Ministry of Ecology portal
Purpose
Designed for continuous automatic monitoring of CO, NO and NO₂ concentrations.
Measurement ranges
10
4 parametersSG1220 Gas Analyzer — Technical Specifications
- Component
- Symbol · Range, mg/m³
- CO
- CO · 0–1000
- NO
- NO · 0–200
- NO₂
- NO₂ · 0–500
11
16 parametersUnit 11
- Model
- SG1220
- Basic error
- ±0.05% of full scale
- Output signal
- 4–20 mA, RS485, TCP/IP (optional)
- Ingress protection
- IP50 / IP54
- Optical tube length
- 500 mm
- Ambient temperature
- –25…+70 °C
- Sample temperature
- +5…+300 °C
- Sample pressure
- 0.7–3.0 bar
- Stack diameter
- 1500 mm
- Analysis method
- DOAS
- Response time
- ≤200 s
- Linearity error
- ≤±5% FS
- Zero drift (24 h)
- ≤±2.5% FS
- Span drift (24 h)
- ≤±2.5% FS
- Power supply
- 220 V, 50 Hz
- Alarm signaling
- Dry contact
Operating Principle
The SG1220 is based on UV-DOAS differential optical absorption spectroscopy, which provides high accuracy in detecting low concentrations.FAT and SAT Tests
- FAT — factory acceptance test
- SAT — site acceptance test
- Conducted with the participation of AFEXGROUP engineers
- Results are documented
Certificates
- ISO 9001
- IEC 61207-7
- ATEX / Ex-proof
- Compliance with the environmental requirements of Uzbekistan
Automated Environmental Monitoring and Reporting System
The system provides continuous monitoring, archiving, analysis and online data transmission. Functions:- Archive of up to 5 years
- Online software and web interface
- Minute, 20-minute, hourly, daily, monthly and annual reports
- Separate visualization for each stack
- Integration with SCADA
- Expandable to up to 6 monitoring points
Equipment Configuration
- Industrial computer
- Monitor, keyboard, mouse
- Operator furniture set
- UPS
AFEX · CONSULTATION
Operators onlineQuick price request
Leave your name and phone number — our specialist will take care of the rest.
EquipmentCEMS Stations: Continuous Multi-Gas Monitoring System for Industrial PlantsYour data is never shared with third parties
Specifications
Data provided by the manufacturer; configuration may vary per order.
Measured Components and Measurement Ranges
5 parameters- Component
- Symbol · Measurement range, mg/m³
- Methane
- CH₄ · 0–300 mg/m³
- Nitrogen oxides
- NO, NO₂ · 0–300 mg/m³
- Carbon oxides
- CO, CO₂ · 0–300 mg/m³
- Sulfur dioxide
- SO₂ · 0–100 mg/m³
02
Gaseous Pollutant Monitoring Subsystem
5 parameters- Item
- Model and description
- Gas analyzer
- SG1220
- Sampling probe
- PSG355
- Sample conditioning system
- CEMS1220
- Electrically heated sampling line
- Dual-core
03
Data Acquisition and Processing Subsystem
4 parameters- Item
- Description
- Data acquisition and processing system
- Hardware and software complex including a computer
- Switching cabinet
- JCB265
- CEMS monitoring software V2.0
- CEMS Monitor
04
VOC Monitoring Subsystem
5 parameters- Item
- Model · Note
- Online VOC analyzer
- VM1700-N · Methane (CH₄)
- Gas sample conditioning system
- — · Includes filtration, condensation and heating
- Electrically heated sampling line
- Stainless steel · Length 500 mm, +5…+300 °C
- Sampling probe
- PSG355 · Stack diameter 1500 mm
05
Data Acquisition Subsystem
3 parameters- Item
- Description
- Data acquisition system (with computer)
- —
- VOC monitoring software
- CEMSmonitor V1.0
06
Pneumatic System
4 parameters- Item
- Model · Note
- Hydrogen generator
- SPH-300AT · 0.7–3.0 bar
- Zero air generator
- ZA1700 · For calibration and purging
- Compressed air purification system
- — · 99.9% purification efficiency
07
Auxiliary Materials
2 parameters- Item
- Description
- Commissioning accessories kit
- —
08
Unit 8
14 parameters- Measured components
- CH₄, CO, CO₂, NO, NO₂, SO₂
- Measurement range
- 0–300 mg/m³; SO₂ – 0–100 mg/m³
- Measurement method
- UV-DOAS differential spectroscopy
- Sample temperature
- +5…+300 °C
- Ambient temperature
- –20…+70 °C
- Sample pressure
- 0.7–3.0 bar
- Ingress protection
- IP50 / IP54
- Output signals
- 4–20 mA, RS485, TCP/IP
- Power supply
- 220 V, 50 Hz
- Stack diameter
- 1500 mm
- Emission source height
- 35 m
- Probe material
- Stainless steel
- Access control
- Protection against unauthorized opening
- Alarm signaling
- Dry contacts, configurable
09
Additional Equipment
5 parameters- Item
- Description
- UPS 3000 VA
- 60–120 minutes of backup autonomy
- Cabinet air conditioning system
- Protection at temperatures of +45 °C and above
- IP66 cabinet
- Outdoor type, with thermal insulation
- GSM/4G module
- For data transmission to the Ministry of Ecology portal
10
SG1220 Gas Analyzer — Technical Specifications
4 parameters- Component
- Symbol · Range, mg/m³
- CO
- CO · 0–1000
- NO
- NO · 0–200
- NO₂
- NO₂ · 0–500
11
Unit 11
16 parameters- Model
- SG1220
- Basic error
- ±0.05% of full scale
- Output signal
- 4–20 mA, RS485, TCP/IP (optional)
- Ingress protection
- IP50 / IP54
- Optical tube length
- 500 mm
- Ambient temperature
- –25…+70 °C
- Sample temperature
- +5…+300 °C
- Sample pressure
- 0.7–3.0 bar
- Stack diameter
- 1500 mm
- Analysis method
- DOAS
- Response time
- ≤200 s
- Linearity error
- ≤±5% FS
- Zero drift (24 h)
- ≤±2.5% FS
- Span drift (24 h)
- ≤±2.5% FS
- Power supply
- 220 V, 50 Hz
- Alarm signaling
- Dry contact
Included units
Units and accessories included with the equipment. Specifications for each are in the section above.
- 01
Measured Components and Measurement Ranges
5 parameters
- Methane: CH₄ · 0–300 mg/m³
- Nitrogen oxides: NO, NO₂ · 0–300 mg/m³
- 02
Gaseous Pollutant Monitoring Subsystem
5 parameters
- Gas analyzer: SG1220
- Sampling probe: PSG355
- 03
- 04
VOC Monitoring Subsystem
5 parameters
- Online VOC analyzer: VM1700-N · Methane (CH₄)
- Electrically heated sampling line: Stainless steel · Length 500 mm
- 05
- 06
- 07
- 08
- 09
SG1220 Gas Analyzer — Technical Specifications
4 parameters
- CO: CO · 0–1000
- NO: NO · 0–200
Spare Parts Kit
7 items
- 1Filters
- 2Thermocouples
- 3Pressure sensors
- 4Valves, solenoids
- 5Temperature controllers
- 6Vacuum pumps
- 7Filter elements
Delivery and commissioning
From consultation to launch — four steps under contract.
Consultation
We define your needs, configure the line and prepare an offer.
Contract
Timeline, payment terms and warranty are fixed in the contract.
Delivery
The equipment is delivered from the manufacturer to your site.
Installation and training
Our specialists commission the equipment and train your operators.
Frequently asked questions
The most common questions about delivery, contracts and tracking.
Is it possible to track my orders online?
You can track orders online. Uzbekistan was one of the first to develop a mechanism for monitoring cargo, determining their location, and estimating the time of arrival using the GPS system. You can get this information only by entering the contract number.
How long will the shipments be delivered?
Delivery time depends on the manufacturer in most cases. Most large-scale production equipment takes 2-3 times longer to deliver than normal equipment. In the case of ready-made equipment, the delivery period starts from 30 days. Excluding the time required for customs clearance of equipment in the territory of Uzbekistan, certification processes.
What are the shipping methods available?
According to the type of goods from abroad and the period when the order was received, the goods are delivered to the territory of Uzbekistan on the following basis:
By air
By rail
By land transport
By mixed transport
What is required of me to conclude a contract?
To become a client of our company, you must:
CERTIFICATE certifying the business entity;
Bank details;
STIR number;
Copy of the manager's passport;
Enterprise seal to confirm the contract
Consultation
Let’s discuss your project together
Contact us for advice on choosing equipment, technical solutions and offers.
AFEX · SOCIAL
Follow our channels
New equipment, commissioning and production footage — on our official channels.
Related equipment
Other equipment
Electric order picking equipment
Details →
Water and beverage equipment
Water Purification Filter AFEX 250 L/h
Details →
Other equipment
Car loading conveyor
Details →
Other equipment
Hydraulic lifting equipment
Details →
Other equipment
PVC pipe gluing equipment
Details →
Other equipment
robotic forklift equipment AFBOT30
Details →
Other equipment
Marker production line
Details →
Other equipment
Wood effect decorative panels production line
Details →
