1 / 1Tire balancing equipment AF-SH015
AF-SH015 is a wheel balancer that also handles heavy vehicle tires weighing up to 150 kg.
- Motor power
- 320w
- Voltage
- 220v
- Max tire weight
- 150 kg
- Balancing speed
- 200 rpm %
- Weight
- 160kg
- Tire pressure
- 40mm-510mm
Overview
About the equipment
AF-SH015 is a wheel balancer that also handles heavy vehicle tires weighing up to 150 kg. Balancing takes 8 seconds, with automatic calibration.
It uses centre balancing, runs at a balancing speed of 200 rpm and has a balancing error of ±1–5 g. Automatic calibration, A.B.D reading and ALU functions are included; the ALU mode is used for balancing alloy wheels. The motor is rated at 320 W, and the machine runs on 220 V.
Tire size range is 10–24 inches, with widths of 1.5–20 inches (40–510 mm). The machine itself weighs 160 kg and is made in Dalian, China. Because it handles tires up to 150 kg, it suits service centres and fleets that work with heavy vehicles as well as passenger cars. This equipment is in stock at the AFEX warehouse.
AFEX supplies the equipment and provides installation, commissioning and warranty service. Tell us what vehicles you service, and we will recommend a suitable balancer.
Car tire balancing equipment (for automatic cargo and heavy machinery)
- Produced
- China
- City
- Dalian
- Max tire weight
- 150 kg
- Balancing speed
- 200 rpm %
- Balancing error
- +1 -5g
- Tire size
- 10-24 inch
- Tire pressure
- 1,5-20 ( 40mm-510mm)
- Weight
- 160kg
- Time to balance
- 8 sek
- Automatic calibration
- There is
- Kind of balancing
- Balancing from the center
- A B D reading function
- There is
- ALU function
- There is
- Motor power
- 320w
- Voltage
- 220v
Quick price request
Leave your name and phone number — our specialist will take care of the rest.
EquipmentTire balancing equipment AF-SH015Your data is never shared with third parties
Specifications
Data provided by the manufacturer; configuration may vary per order.
Car tire balancing equipment (for automatic cargo and heavy machinery)
15 parameters- Produced
- China
- City
- Dalian
- Max tire weight
- 150 kg
- Balancing speed
- 200 rpm %
- Balancing error
- +1 -5g
- Tire size
- 10-24 inch
- Tire pressure
- 1,5-20 ( 40mm-510mm)
- Weight
- 160kg
- Time to balance
- 8 sek
- Automatic calibration
- There is
- Kind of balancing
- Balancing from the center
- A B D reading function
- There is
- ALU function
- There is
- Motor power
- 320w
- Voltage
- 220v
Delivery and commissioning
From consultation to launch — four steps under contract.
Consultation
We define your needs, configure the line and prepare an offer.
Contract
Timeline, payment terms and warranty are fixed in the contract.
Delivery
The equipment is delivered from the manufacturer to your site.
Installation and training
Our specialists commission the equipment and train your operators.
