1 / 1Fixed equipment AF-SD12 for brake discs
AF-SD12 is a stationary brake lathe that machines brake discs to restore a flat working surface.
- Voltage
- 220v
- Main motor
- 0,75 kw 1HP motor
- isk weight
- 186 kg
- shear speed
- 98rpm
- Weight
- 350kg
- Disc maximum thickness
- 48mm
Overview
About the equipment
AF-SD12 is a stationary brake lathe that machines brake discs to restore a flat working surface. Machining accuracy is 0.005 mm, for discs up to 48 mm thick.
The lathe turns the brake disc at 98 rpm and removes a thin layer from the working surface. After machining, surface roughness is Ra 1.5–2.0. Rotor diameter is 381 mm, and the main motor is rated at 0.75 kW (1 HP).
The machine runs on 220 V, weighs 350 kg and has a working height of 1 m to 1.25 m. It is designed for car service centres and brake repair workshops: discs with vibration or uneven wear can be machined and reused instead of replaced, as long as their thickness allows.
AFEX supplies the equipment and provides installation, commissioning and warranty service. Tell us the brake disc sizes your shop works with, and we will check that the lathe fits.
General
- Disc maximum thickness
- 48mm
- Accuracy level
- 0,005mm
- isk weight
- 186 kg
- Voltage
- 220v
- shear speed
- 98rpm
- Main motor
- 0,75 kw 1HP motor
- Working height
- min 1 m max 1,25 m
- Brake disc smoothness level
- Ra 1,5-2,0 um
- Weight
- 350kg
- Rotor diameter
- 381mm
Quick price request
Leave your name and phone number — our specialist will take care of the rest.
EquipmentFixed equipment AF-SD12 for brake discsYour data is never shared with third parties
Specifications
Data provided by the manufacturer; configuration may vary per order.
General
10 parameters- Disc maximum thickness
- 48mm
- Accuracy level
- 0,005mm
- isk weight
- 186 kg
- Voltage
- 220v
- shear speed
- 98rpm
- Main motor
- 0,75 kw 1HP motor
- Working height
- min 1 m max 1,25 m
- Brake disc smoothness level
- Ra 1,5-2,0 um
- Weight
- 350kg
- Rotor diameter
- 381mm
