Laser Plotter AF-980P — Image 1 / 31 / 3
Printing equipment

Laser Plotter AF-980P

400–450 W · 50 W · AF-980P / AF-1390P / AF-1750P

Individual offer
Machine power
400–450 W
Laser power
50 W
Model
AF-980P / AF-1390P / AF-1750P
Cutting speed
10–800 mm/s
Laser current
0–30 mA
Operating voltage
AC 220V ±10%
Price

Overview

Key advantages

  • Genuine USB2.0 and RS232 interfaces eliminate the slow transfer speeds and unstable connections of traditional low-speed plotters
  • The device software can be updated remotely over the network

About the equipment

 Applicable Materials

  1. Two-layer materials: self-adhesive stickers, standard reflective film, high-strength 3M reflective film, car stickers, garment lettering film, flag foam film and more.
  2. Single-layer materials: polyester film, insulating paper, kraft paper, white cardboard, ABS sheet (≤0.5 mm), PVC (≤0.8 mm), two-color sheet (at low speed) and other soft non-metallic materials.
01

General

21 parameters
General
Model
AF-980P / AF-1390P / AF-1750P
Working width (roll width)
980 / 1390 / 1750 mm
Cutting width
830 / 1240 / 1600 mm
Cutting length
unlimited
Cutting thickness
Blade ≤0.5 mm, laser ≤0.8 mm
Media feed system
Knurled aluminum roller
Pressure device
Adjustable dual-spring pressure mechanism
Drive
Microstepping stepper motor
Cutting speed
10–800 mm/s
Blade pressure
0–510 g
Laser current
0–30 mA
Operating voltage
AC 220V ±10%, 50 Hz
Machine power
400–450 W
Laser power
50 W / 80 W (optional)
Interface
Serial port, USB, flash drive
Command language
HPGL
Data transfer rate
38.4K
Software
Wentai, CDR, Signmaster and others
Operating environment
Temperature: +1℃ – +35℃, relative humidity: 10%–50%, non-condensing
Dimensions
2050 × 560 × 600 / 2050 × 560 × 600 / 2320 × 560 × 600 mm
Weight
90 / 95 / 110 kg
AFEX · CONSULTATION
Operators online

Quick price request

Leave your name and phone number — our specialist will take care of the rest.

EquipmentLaser Plotter AF-980P

Your data is never shared with third parties

Specifications

Data provided by the manufacturer; configuration may vary per order.

General

21 parameters
Model
AF-980P / AF-1390P / AF-1750P
Working width (roll width)
980 / 1390 / 1750 mm
Cutting width
830 / 1240 / 1600 mm
Cutting length
unlimited
Cutting thickness
Blade ≤0.5 mm, laser ≤0.8 mm
Media feed system
Knurled aluminum roller
Pressure device
Adjustable dual-spring pressure mechanism
Drive
Microstepping stepper motor
Cutting speed
10–800 mm/s
Blade pressure
0–510 g
Laser current
0–30 mA
Operating voltage
AC 220V ±10%, 50 Hz
Machine power
400–450 W
Laser power
50 W / 80 W (optional)
Interface
Serial port, USB, flash drive
Command language
HPGL
Data transfer rate
38.4K
Software
Wentai, CDR, Signmaster and others
Operating environment
Temperature: +1℃ – +35℃, relative humidity: 10%–50%, non-condensing
Dimensions
2050 × 560 × 600 / 2050 × 560 × 600 / 2320 × 560 × 600 mm
Weight
90 / 95 / 110 kg
